Streamer DST-1100

$100.00

Designed to broadcast television content in IPTV networks.
The streamer allows the operator, in addition to broadcasting in cable networks or terrestrial broadcasting networks, to quickly and inexpensively organize broadcasting in IP networks.

Download PDF:
English, Русский

Category:

Main functions

  • Convenient, intuitive control program;
  • Work in real time;
  • Diagnostics by SNMP management system;
  • The use of ASI input for a detailed analysis of the structure of the transport stream and the measurement of bitrates;
  • Assignment of any PID for all incoming flow tables;
  • The presence of non-volatile, hardware real-time clocks allows you to organize a stable IP broadcast, unlike streamers organized using the system clock of control computers;
  • Support for SPTS and MPTS input transport streams;
  • Stream processing with SD and HD services;
  • Processing of encoded and / or non-encoded streams;
  • The total speed of the output stream is 650 Mb \ s;
  • Supports broadcast modes: multicast and unicast;
  • Supports UDP / RTP;
  • In the case of the formation of one multi-program output stream, when it is transmitted via the RTP protocol, noise-resistant coding (FEC) is provided according to SMPTE2022, Pro-MPEG COP3R2 and RFC2733, RFC3009, RFC5109;
  • Works with both VBR and CBR streams;
  • At the output, up to 256 programs are transmitted simultaneously;
  • Each stream has its own IP address (multicast or unicast);
  • When broadcasting IPTV channels, a number of service tables are automatically created, such as PAT, PMT, SDT;
  • The presence of LCD display and indicators allows you to monitor the current status of the device, its input and output signals;
  • Device software update via Ethernet control port.
